Product Details:
Payment & Shipping Terms:
|
| Product Name: | 1000~50000 Liters Foam Bladder Tank, Fire Fighting Foam Buffer Tank GB4986 Standard | Material: | Carbon Steel |
|---|---|---|---|
| Nominal Size: | Customized | Construction: | Vertical Or Horizontal Type |
| OEM Or ODM Service: | Available | Third Party Inspection: | Or Other Available Inspection |
| Function: | Chemical, Biological Reaction | Key Words: | Foam Bladder Tank/fire Fighting Foam Buffer Tank |
| High Light: | carbon steel pressure vessel,pressure sealed tank |
||
|
Product Name: Fire Fighting Foam Buffer Tank |
OEM or ODM: Available |
Model Number:ZY-T009 |
|
Place of Origin: Shanghai China |
Materials: Carbon Steel |
Size: Customized |
|
Flow Rate: 4/8/16/24/32/64/80/100 |
Proportion: 1%, 6% or 3% |
Construction:Vertical or Horizontal Type |
|
Details For Fire Fighting Foam Buffer Tank |
ZHIYOU MARINE |
|
www.marineoutfittings.com |
Foam baldder tanks can be formed to high, medium and low expansion foam extinguishing system with high and medium and low expansion foam generator, air foam spray gun and so on. The system is widely used in foam fire extinguishing system, such as chemical industrial enterprises, port and dock, large oil storage, airport oil storage, oil or fuel power plants, boiler room, dangerous goods storage, chemical warehouses and so on.
Foam bladder tanks is made from tank, bladder, pressure-type proportioner, safety valves, control valves, level gauge and a lot of ancillary components. Pressed water is divided into two parts according to a certain ratio(1: 99 or 3: 97 or 6: 94), 99%(97% or 94%) of the pressed water flow to the Proportioner, and 1%(3% or 6%) of the pressed water flow to the interlayer between tank and bladder, the water in interlayer will push foam concentrate in bladder into Proportioner. Foam concentrate will be injected into pressed water that flows through the proportioner and form foam solution, then the foam solution will flow to foam producing equipment, such as foam chamber and so on. Finally, air-foam concentrate is applied to put out fire.
The foam concentrate in the bladder can be used next time because it doesn't contact with water.
Type of Proportioner: 1%, 3%, 6%.
|
Features Of Fire Fighting Foam Buffer Tank |
ZHIYOU MARINE |
|
www.marineoutfittings.com |
1. To ensure the water tank internal membrane structure not in contact with the tank wall, so no rust inside the tank wall, external condensation phenomenon, greatly extend the service life.
2. The rubber diaphragm can relax more than 200000 times, after filling can be use for a long time.
3. Gentle and water pressure fluctuation in the system can effectively reduce the start-stop frequency of the pump.
4. The diaphragm for food grade natural rubber diaphragm can be applied in the drinking water system.
|
Parameter Of Fire Fighting Foam Buffer Tank |
ZHIYOU MARINE |
|
www.marineoutfittings.com |
| Model | volume(m3) | Max.flow rate (L/S) | Inner diameter of tank (mm) |
Working Pressure (MPa) |
Mixing ratio |
Inner diameter of solution pipe(DN mm) |
| ZY-T009-1 | 0.5 | 4--8 | 800 | 0.6-1.2 | 1%,3% or 6% | 50/65 |
| ZY-T009-2 | 1 | 1000 | 50/65 | |||
| ZY-T009-3 | 1 | 4--32 | 1000 | 50/65 | ||
| ZY-T009-4 | 2 | 1200 | 100/150 | |||
| ZY-T009-5 | 3 | 1400 | ||||
| ZY-T009-6 | 3 | 32--64--80 | 1400 | |||
| ZY-T009-7 | 4 | 1600 | ||||
| ZY-T009-8 | 5 | 1600 | ||||
| ZY-T009-9 | 6 | 1800 | ||||
| ZY-T009-10 | 7 | 1800 | ||||
| ZY-T009-11 | 7.6 | 1800 | ||||
| ZY-T009-12 | 8 | 1800 | ||||
| ZY-T009-13 | 9 | 2000 | ||||
| ZY-T009-14 | 10 | 2000 | ||||
| ZY-T009-15 | 12 | 2200 | ||||
| ZY-T009-16 | 15 | 2200 |
All products can be customized as your requirement.
|
Part Of Our Storage Tanks |
ZHIYOU MARINE |
|
www.marineoutfittings.com |
|
Product name |
Specification (mm) |
pressure |
Category (GB) |
Material (GB) |
|
Flash evaporator |
Φ2000*8 |
0.10/1.3/1.8 |
II |
S30408 |
|
Low temperature shift converter |
Φ4000*12358*20 |
0.8 |
II |
Q345R |
|
Variable furnace |
Φ4000*13360*22 |
0.8 |
II |
Q345R |
|
Compressed air tank |
Φ3000*14*7436 |
0.88 |
II |
Q345R |
|
Molecular sieve adsorber |
Φ3800*16*8600 |
0.8 |
I |
Q345R |
|
Desulfurization tank |
Φ3200*40*16730 |
2.47 |
III |
Q345R |
|
Pre-desulfurzation tank |
Φ2600*30*11700 |
2.5 |
III |
Q345R |
|
Heating furnace |
Φ3200*6*21920 |
1.0 |
II |
Q235-A |
|
Preheat oven |
Φ5456*8*36770 |
2.33 |
II |
Q235-A |
|
Conversion furnace |
Φ3000*34*20495 |
2.3/0.36 |
III |
Q345R |
|
Chlorine tank |
Φ3200*28*25586 |
2.2 |
III |
Q345R |
|
Silicon tetrachloride tank |
Φ3400*14*11654 |
1.0 |
II |
S30408 |
|
200m3 LPG storage tank |
Φ3800*20*18642 |
1.77 |
III |
Q345R |
| Package & Delivery& Payment terms | ZHIYOU MARINE |
| www.marineoutfittings.com |
| Our Service | ZHIYOU MARINE |
| www.marineoutfittings.com |
Zhiyou has been doing OEM job for many reputable companies for many years, which makes the best
guaranty for Zhiyou technical advantages with precise design. Zhiyou Marine& Offshore is designed
according to ABS CCS BV LR DNV NK KR etc standard.In line with the responsibility spirit for customers,
we try to satisfy the standards and the customers’ requirement in the process of designing and
manufacturing process, as well as fully consider the basic cost. The products we providing will guarantee
the quality and reasonable price, which ensure our cooperated customers can get the maximum value
and minimum cost.
1) Punctual delivery:
• We put your order into our tight production schedule, keep our client informed about production
process, ensure your punctual delivery time.
• Shipping notice/ insurance to you as soon as your order is shipped.
| Quality Guarantee | ZHIYOU MARINE |
| www.marineoutfittings.com |
| Our Related Products | ZHIYOU MARINE |
| www.marineoutfittings.com |
OUR PRODUCT RANGE
| 1 | Marine door | Watertight | Fireproof | Quick action | Weather tight | Airtight&Sound-reduction | Hydraulic Watertight | Hollow Cabin Door |
| 2 | Marine windows | Fixed | Skylight | Porthole | Sliding | Watertight | Fireproof |
Louver& Cabin Shutters |
| 3 | Hatch cover& man hole | Sliding | Watertight Manhole Cover | Bolted watertight | Suez Canal Light | Quick action | Type A B C D | Rotating Oil tight |
| 4 | Mooring component | Marine bollards | Fairlead | Mooring roller | Mooring chock | |||
| 5 | Marine steel product | Seamless steel Pipe | Seam steel pipe | Marine crane | Marine Stern Roller | Marine fender rubber cylinder | Steel structure | API pipe |
| 6 | Marine propeller& shaft | Rudder System | propeller | Rudder shaft sealing component | Rudder blade | Rudder carrier bearing | Rudder stock/pintle sealing apparatus | Fin stabilizer |
| 7 | Marine deck equipment | Mooring winch | Crane | Windlass | Capstan | Rope Guider | Cable lifter | |
| 8 | Rubber elements | Rubber fenders | Pneumatic fender | Ship launching airbag | Rubber sealing strip | Quay fenders | Drain airbag | |
| 9 | Pressure vessel tank | Anti- Corrosion pressure | Fermentation tank | Low temperature pressure | Compressor air tank | Oil& LPG tank | Vacuum tank | Foam buffer tank |
| 10 | Marine boarding ladder& gangplank | Boarding ladder | Draft ladder | Lifesaving ladder | Vertical access ladders | Embarkation ladder | Accommodation ladder | Gangplank |
| 11 | Welding material | E 6013 | E 7018 | E 7024 | E 7018-1 | E 308L-16 | E 347L-16 | E 309L-16 |
| 12 | Metal Processing Machinery Parts | Machinery Parts or fittings can be designed as your drawings or detailed requirements, and processed by lathes, milling machines, planing machines, drills. | ||||||
NOTES:
1. The content of this table doesn't cover all catagories, providing that the item you are looking for is not included hereof, please feel free to contact us.
2. All the products shall be customerized accordingly, OEM&ODM available.
